Conveyors

A conveyor is a piece of equipment designed to move bottles efficiently through automated packaging systems, including filling, capping, and labeling lines. These robust, long-lasting conveyors are made in Canada and feature a stainless steel frame for durability. They are equipped with a low-friction acetal tabletop plastic chain belt and driven by a variable-speed DC motor with controller, allowing operating speeds of up to 200 feet per minute.

Key Features

  • 304 Stainless Steel Frame

  • Powered by a Variable-speed Motor & Controller

  • Adjustable Guide Rails

  • Adjustable Leveling Feet

  • Custom lengths available from 5ft to 20ft

  • Floor to Belt Height: Adjustable from 35-40 inches

  • Guide Rail Height: Adjustable from 0.5 - 4 inches

  • Speed: Up to 200 feet/minute

  • Electrical Requirements: 110 VAC, 60HZ, Single Phase

​Plastic chain belt

Stainless Steel belt

In line conveyor

Accumulation Tables

An accumulation table is a purpose-built machine with a circular, motorized rotating surface designed to organize, collect, or distribute bottles within a packaging line. These tables can be positioned at the start, middle, or end of production to manage bottle flow, absorb production variations, and support continuous, efficient operation.

When installed at the beginning of a bottle packaging line, a rotary accumulation table allows operators to load large quantities of empty bottles at once instead of feeding them individually onto a conveyor. The rotating surface then smoothly releases the bottles in a single-file stream, ensuring a consistent and controlled feed into the system.

Placed in the middle of a packaging line, rotary accumulation tables function as buffer zones that help balance speed differences between upstream and downstream equipment. During production surges or temporary slowdowns, excess bottles are held on the rotating table, preventing congestion and downtime. As conditions normalize, the bottles are released gradually, maintaining steady throughput and overall line efficiency.

At the end of a bottle packaging line, rotary accumulation tables provide a controlled collection point for finished containers. By temporarily holding completed bottles, they prevent line backups and give operators the flexibility to pack, inspect, or label products without interrupting upstream operations, ensuring a smooth and uninterrupted workflow.

Key Features

  • 304 Stainless Steel Frame

  • Clockwise and Counterclockwise Rotation

  • Powered by a Variable-speed Motor & Controller

  • Adjustable Bottle Guide Rails

  • Adjustable Leveling Feet

  • Custom sizes available.

  • Floor to Disk Height: Adjustable from 35-39 inches

  • Disk Thickness: 1/8 inches (11 Gauge)

  • Speed: 0-8 RPM

  • Max Weight Capacity: 300 pounds

  • Electrical Requirements: 115 Volts, 60HZ, Single Phase

In-feed Table

Accumulation Table

Infeed Table
Accumulation Table

Financing Available for New Machines
